Plastic Metal Separator

$1,700.00 – $2,900.00

The raw materials going through the detector as falling method ②, start up the separator once has detecting the metal⑤, then split the metal particles④ from raw materials out to the separation mouth, while qualified products would falling to the discharge tube.

Advantage:Intelligent detection, maintenance-free.The contacting parts is made of 304 stainless steel.Special structure design can effectively avoid vibration,effect of external factors such as interference noise and products.A variety of caliber optional, Model meets all of the actual application.Can avoid product accumulation, Obstruction caused by the mould.

SKU: N/A Category: Tag:

plastic metal separator Specifications

Features:

1.Collection of detecting coil, controller, separating unit as an unit,Installation is simple to use.

2.To quickly remove through eliminating device, to reduce the material loss to the greatest extent.

3.The installation height of small,easy integration.

4.Test material properties: dry, good liquidity, no long fiber, no conductivity.

5.Test material temperature: Less than 80 ℃, the temperature is more than this range, the optional special high temperature option.

6.Controller can choose to install in detecting position 10 m.

7.Level of protection: IP65

8.Mainly used for detection of loose granular materials (particle < 8 mm) in gravity gravity feed, can be used in the plastics industry, food industry, chemical industry.

Feed pipe diameter

35mm/50mm/70mm, 80mm, 100mm, 120mm
Maximum Throughput(L/H)

400~16000
Detecion Sensitivity

Fe:0.3mm Non-Fe:0.4mm SUS:0.6mm ~ Fe:1.2mm Non-Fe:1.5mm SUS:2.0mm
