Honeycomb Dehumidifier

(1 customer review)

$4,200.00$19,600.00

HF series honeycomb dehumidifier normally works together with hopper dryers to dry some highly hygroscopic materials. The dehumidifier is mainly used to provide low dew point dry air with average dew point temperature of -40℃.

Honeycomb Dehumidifier
Working with hopper dryer,the denumidifier is used to dehumidify engineering plastics which is highly hygroscopic,such as PA,PC,PBT,PET,etc.

Honeycomb Dehumidifier Specifications Working flow chart of honeycomb dehumidifier

Features:

1. Honeycomb dehumidifying adopts P.I.D.temperature controller to accurately control regenerative temperature.

2. Honeycomb wheel can provide dew point of -40℃ or even lower, after enhance the configuration, dew point can reach below -50℃.

3. Centralized automatic control can be realized by optionally selected PLC touch screen controller.

4. Dew point sensor is optional, which can monitor the dehumifiying effect all the time.

5. For dehumidifying drying unit, heat exchanger is optional to realize heat recycling with which 30% energy can be saved.

6. CE certified.

Company introduction:

Since its establishment, Hengju has been focusing on the research and development of dehumidifying & drying, dosing & mixing and central conveying systems to make products closer to customer’s demand and customize complete automation solutions for customers.
Hengju Machinery can provide you with complete plant automation solutions and central chiller plant design. We have 15 years of industry experience and 8,000 square meters of self-built workshops, providing services for hundreds of companies, tailor-made solutions, free design renderings, and 24-hour online communication services.
Relying on strong professional technology and stable quality, we have won high comments from customers at home and abroad.Covering industries include auto parts, chemical industry,pelletizing, new energy, new materials, etc., and excellent performance in bio-degradable plastics such as PLA, PBAT, and pipe/sheet/ cable extrusion and other fields!

Type

HF-200, HF-300, HF-400, HF-500, HF-700, HF-1000, HF-1500, HF-2000

Dryer hopper capacity(L/hr)

25/40/80/120

Dry-air dew poin

-40℃

Temperature(℃)

80~180

Air flow(m^3/h)

80

Blower power(KW)

0.75

Regeneration blower(KW)

0.25

Drying heater(KW)

3/3/3.9/4.2

Regeneration heater(KW)

2.7/3.8/3.8/3.8

Conveying blower(KW)

0.75

Dimension LxWxH(cm)

100x87x180

Approx.Net Weight(KG)

310
